EPDM PTFE Gaskets

EPDM (Ethylene Propylene Diene Monomer) is a synthetic rubber elastomer used in gaskets for its excellent sealing memory, temperature resistance, and resilience. In PTFE x EPDM composite gaskets, the EPDM core provides the spring-back force that maintains sealing pressure over time, helping prevent leaks even under minor ferrule misalignment or thermal cycling.

A PTFE (Polytetrafluoroethylene, also known as Teflon) gasket is a sealing component made from chemically inert fluoropolymer material. PTFE gaskets offer broad chemical resistance and are non-reactive, making them ideal for pharmaceutical, food, and chemical applications. However, pure PTFE gaskets are susceptible to creep and cold flow — a limitation addressed in PTFE x EPDM envelope designs.

Artesian Systems offers EPDM PTFE gaskets in sizes ranging from 1.5" up to 12", including 1.5", 2", 3", 4", 6", 8", 10", and 12" for both the envelope and unitized designs. These cover the most common tri-clamp sanitary ferrule pipeline sizes used in food, pharmaceutical, and chemical processing.

Yes. Artesian Systems' EPDM PTFE gaskets are compliant with FDA 21 CFR 177.2600, which governs rubber materials intended for contact with food and pharmaceutical products. They also meet GMP (Good Manufacturing Practices) requirements, making them suitable for regulated food processing, pharmaceutical manufacturing, and biotechnology applications.

Envelope gaskets feature a PTFE outer wrap encasing an EPDM filler core in an un-flanged design, providing flexibility for slight ferrule misalignment. Unitized gaskets use a one-piece bonded construction where PTFE is directly bonded to the EPDM core, reducing component movement and improving installation stability. Both designs combat creep and cold flow seen in PTFE-only gaskets.

Artesian Systems' EPDM PTFE gaskets have a 10-year shelf life from the cure date. For optimal longevity, store them in original packaging in a clean, dry environment at temperatures between 65°F and 85°F. Keep gaskets away from direct sunlight and at least 6 feet from electric motors to prevent premature degradation of the elastomer material.
