Sanitary Filters for Water Testing & Environmental Labs

NSF 42 certifies filters for aesthetic effects, meaning they reduce chlorine, taste, and odor from drinking water. NSF 53 certifies filters for health effects, confirming they reduce contaminants such as lead, cysts, or volatile organic compounds (VOCs) that pose health risks. Together, these certifications indicate a filter meets both cosmetic and health-protective standards for drinking water systems.

Water testing filtration typically uses membrane or screen filtration to capture particulates, microorganisms, or contaminants from a water sample for analysis. Inline sanitary screen gaskets, like those from Artesian Systems, strain particles at defined micron ratings (5, 20, or 100 micron) to protect instrumentation and isolate target analytes in environmental and drinking water lab workflows.

Artesian Systems offers tri clamp screen gaskets in 5 micron, 20 micron, and 100 micron filtration ratings. The 5-micron option provides the finest particle capture, ideal for pharmaceutical and biotech applications, while 20 and 100 micron options suit food processing, dairy, brewing, and general industrial inline straining requirements.

Available gasket materials include BUNA-N (Nitrile), VITON/FKM, and PTFE/Teflon. BUNA-N is cost-effective for oils, fuels, and mild chemicals. VITON/FKM offers superior resistance to harsh chemicals, solvents, and high temperatures. PTFE/Teflon provides the broadest chemical inertness, making it ideal for highly corrosive or ultra-pure pharmaceutical and laboratory fluid handling applications.

Most models are available in 1.5", 2", 2.5", 3", 4", and 6" tri clamp sizes, accommodating a wide range of standard sanitary pipeline configurations. Size availability varies slightly by gasket material. Note that PSI service ratings for PTFE gaskets do not apply to connections 1" and above due to cold flow potential.

Yes. All Artesian Systems tri clamp screen gaskets have passed U.S.P. Class VI Cytotoxicity testing and comply with FDA 21CFR177.2600 and 21CFR177.1550, confirming biocompatibility for pharmaceutical, biopharmaceutical, and medical device manufacturing. They are also approved by 3-A Sanitary Standards and USDA, making them suitable for the most demanding regulated processing environments.
