PTFE Envelope Gaskets

PTFE gaskets are used in applications requiring high chemical resistance, low friction, and compliance with food or pharmaceutical regulations. Common uses include sanitary piping systems, pharmaceutical bioreactors, food and beverage processing lines, chemical handling equipment, and any tri-clamp ferrule connection where a non-reactive, FDA-compliant seal is required.

Artesian Systems offers PTFE Envelope Gaskets in eight tri-clamp sizes: 1.5", 2", 3", 4", 6", 8", 10", and 12". This range covers most standard sanitary pipeline configurations used in pharmaceutical, food, and chemical processing facilities.

Yes. These gaskets are approved under FDA 21CFR177.2600 for food contact materials and fully comply with GMP (Good Manufacturing Practices) for food process applications. They are also compatible with 3A and USDA material standards, making them suitable for regulated pharmaceutical and food processing environments.

It is important to note that the standard 1550 PSI service rating for sanitary clamps does NOT apply to connections 1" and above when using any PTFE gasket, due to the cold flow potential of PTFE. This restriction does not apply to fractional 1/2" and 3/4" sizes, which feature a recessed, fully contained design.

These PTFE/EPDM Envelope Gaskets have a shelf life of 10 years from the cure date. They should be stored in original packaging in a clean, dry warehouse environment, away from direct sunlight, and kept at least 6 feet away from electric motors. Recommended storage temperature is between 65°F and 85°F.

No. These PTFE Envelope Gaskets are specifically designed for tri-clamp (sanitary ferrule) connections and are not recommended for use with bolted clamps. The envelope construction and pressure ratings are engineered for standard sanitary tri-clamp assemblies used in food, pharmaceutical, and chemical processing pipelines.
